Yamaha VF90 VMAX SHO – 25″ Shaft, 2022 Model

Yamaha VF90 VMAX SHO – 25″ Shaft may be the smallest in the V MAX SHO lineup, but it packs a big punch. Its lightweight design combined with 1.8-litre displacement makes the VF90 V MAX SHO the class leader in torque and top speed. Add to that the option of a 25-inch shaft and the VF90 is an exciting new prospect for bass, walleye and muskie anglers.

Features and Benefits

• Multi-Point Fuel Injection: With Multi-point Fuel Injection, Fuel is delivered at the optimum volume and time according to ECU sensor signals. This ensures quick starts, efficient fuel consumption, and ample power along with ultra-low emissions.
• Command Link Compatibility: The VF90 is compatible with Yamaha’s Command Link 6Y8 and 6YC digital gauges, as well as Y-COP®.
• Amp It Up: The VF90 features a three-phase alternator that produces up to 35 amps of power. So there’s plenty of electrical power for battery charging and accessories, with more to spare.
• Peace And Quiet: Yamaha’s Shift Dampener System (SDS™) greatly reduces the force and noise commonly associated with shifting gears for a smoother, quieter ride. The new VF90 is compatible with Yamaha’s exclusive Talon™ SDS™ propellers.
• Power Trim And Tilt: Yamaha VF90 VMAX SHO – 25″ Shaft is equipped with a single compact, lightweight PTT unit. The tilt angle can be adjusted with the optional tilt limiter.
• Multi-Function Tiller Handle: Yamaha’s award-winning Multi-Function Tiller Handle incorporates engine start/stop, emergency stop, gear shift, power trim and tilt operation, variable trolling switch, warning and controls all in one. It can be added as an accessory to the new V MAX SHO 90.

General Information.

Yamaha VF90 VMAX SHO – 25″ Shaft Engine.

Dimensions.

Model Specific Features

• New alternator output: up to 70 gross amps
• Super High Output 60-degree 4.2-liter V6 Design
• Minimum 89 Octane
• Shaft lengths available: 20” and 25”
• New Saltwater Series II™ HP propellers can increase top speed on 25” models in lightweight applications

Yamaha VF90 VMAX SHO – 25″ Shaft Specifications.

• Engine Type: Inline 4-cylinder
• Displacement: 1.8L
• Bore x Stroke: 3.19 x 3.5 in. (81 x 88.9 mm)
• Prop Shaft Horsepower: 250hp at 5500 rpm
• Full Throttle RPM Range: 5000 ~ 6000 rpm
• Alternator Output at W.O.T.: 38 Amp
• Compression Ratio: 10.3:1
• Fuel Induction System: SOHC, 4 valves per cylinder
• Weight †: 257 kg (567 lbs)
• Recommended Fuel: Octane 89
• Engine Oil: Yamalube® 4M (See owner’s manual)
• Recommended Fuel Filtration: Yamaha 10-Micron Fuel/Water Separating Filter (external)
• C.A.R.B. Rating: 3-Star
• Exhaust: Through Propeller
• Intake: 24
• Ignition: TCI Microcomputer
• Spark Plug: LFR6A-11
• Alternator Output: 38 Amp
• Starting System: Electric
• Lubrication: Wet Sump
• Engine Oil Capacity: 6.7L/6.4L
• Recommended Cooling: Water/Thermostatic Control
• Ethanol Blend Limit: 10% Maximum
• Gear Ratio: 1.75:1
• Gear Shift: Forward, Neutral, Reverse
• Shaft Length: 25″
• Degree of Tilt: 66°
• Degree of Trim: -4° through +16°
• Dry Weight: 353 lb. (160 kg)
• Steering Angle (maximum): 35° from center, either direction

Yamaha VF90 VMAX SHO – 25″ Shaft Warranty.

Reach out to us if you want your Yamaha VF90 VMAX SHO – 25″ Shaft customized.
